Blue Sea 8567 AC Toggle Source Selector (230V) - 2 Sources + 4 Positions

MSRP: $428.20
$293.90
You save $134.30
SKU:
20889
UPC:
632085085674
Condition:
Brand New
Availability:
Backordered, Ships ASAP - Order Online to be put in the Queue
  • Blue Sea 8567 AC Toggle Source Selector (230V) - 2 Sources + 4 Positions
  • Blue Sea 8567 AC Toggle Source Selector (230V) - 2 Sources + 4 Positions
30-Day Returns Policy
Authorized Dealer
Free Shipping*
Financing Available

Description

AC Toggle Source Selector (European)


PN: 8567
White Switches

  • (2) 16A Double Pole Circuit Breakers Installed

  • (2) 8A Single Pole Circuit Breakers Installed


  • Features:
    • Double pole AC main circuit breakers with installed lockout slide
    • Prevents connecting both AC sources simultaneously
    • Maximum panel amperage - 50 Amperes
    • Red reverse polarity indicating LED
    • All hot, neutral and safety ground buses installed, fully pre-wired
    • All circuit label positions are backlit on standard panels - No kit required
    • "ON" indicating LEDs installed in all circuit positions
    • MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance
    • Two-part polyurethane slate gray finish
    • Heavy 1/8" aluminum 5052 alloy
    • Industry standard height and width
    • Countersunk mounting holes throughout
    • Detailed installation instructions and cutout template included
    • Includes set of 30 common Large Format Labels
    • Over 500 individual labels available
    • For 230V AC Systems

    WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

    Specifications:

    • Voltage: 230v
    • AC/DC: AC
    • Max Breaker Quantity: 4
    • Box Dimensions: 5"H x 5"W x 12"L WT: 1.35 lbs
    • UPC: 632085085674

    Quick Guide (pdf)
    Owner's Manual (pdf)
